Tektronix 310 A oscilloscope.Very compact oscilloscope for on-site maintenance.
Mass: 10. 7 kg
1 channel
Release date: 1956; Price $ 735. Still in the 1969 Tektronix catalog
Power consumption: 175 W
Bandwidth = 3.5 MHz
Note a calibrator that is a square wave generator at 1 kHz adjustable between 50 mV and 100 V.
Note the high quality cabling on porcelain lugs.
